Activated Carbon Granular Sponge
Activated Carbon Granular Sponge is made of high-quality activated carbon Granular as absorption material. It is adopted of macromolecule adhesive material enclosed at sponge base with excellent absorption performance. It is suitable for exhaust gas filtration and dust filtration in various ventilation systems, painting booth , car air-conditioner, air purifier to remove dust ,foul smell and Volatile organic compounds like Benzene, formaldehyde. What's more, It can be used alone or combine with pre-filter media, the efficiency would be better.
Application:
Various ventilation systems, air conditioning systems, dust removal equipment and exhaust gas purification.
1. Air conditioning and ventilation systems dust removal and deodorization.
2. All kinds of organic exhaust filter purification.
3. Formaldehyde, toluene and hazardous gas adsorption.
4. Home use & commercial use, coating industry exhaust gas emissions purification.
5. Can be customized in pad / pad with frame / roll.
Material and Features:
1. Granular Activated carbon foam uses good granular activated carbon as the base material and foaming to sponge alike material.
2. The strong adsorption capacity for harmful gases such as formaldehyde and toluene.
3. Good dust capture performance, Rich pore structure and large specific surface area, can be trimmed to suit any dimension.
4. Good formability and low airflow velocity resistance.
5. Good deodorizing effect.
6. Good chemical stability and high mechanical strength, resistance to general chemical liquid even weak acid/alkaline, avoid direct and long term sun radiation.
Technical Parameters:
1. Adsorption objects: ≥ all kinds of organic gases
2. Filter efficiency: G3~G4 (EN779)
3. Flame retardant rating: F1（DIN 53438）、B1（GB/T 17591-2006）
4. Final pressure drop: 200pa(recommended)
5. Humidity resistance (Relative humidity): ≤80%RH
6. Resistance to temperature: ≤100℃
7. Instantaneous temperature resistance≤120℃
8. Equilibrium adsorption capacity of toxic gas(mg/g)
| Formaldehyde | 320 |
| Aether | 470 |
| Carbinol | 260 |
| Toluol | 320 |
| Xylene | 290 |
| Chloroform | 530 |
| Benzine | 290 |
| Sulfureted hydrogen | 1060 |
| Sulfur dioxide | 830 |
| Hydrogen chloride | 450 |
Technical Specification:
| Model | Dimension | Carbon content (%) | Benzene adsorption (%) | Recommended adsorption airflow speed (m/s) | ||
L (m) | W (m) | T(mm) | ||||
FRS-ACGS | 2 | 1 | 3~200 | ≥50% | ≥28% | ＜0.5 |
Remarks: other specification are available on request. | ||||||
Product Real Shot:
